Cisco® Aironet® 3500 Series Access Points with Cisco CleanAir technology are the industry's first 802.11n access points to create a self-healing, self-optimizing wireless network. CleanAir technology is a systemwide feature of the Cisco Unified Wireless Network that improves air quality by detecting RF interference that other systems can't recognize, identifying the source, locating it on a map, and then making automatic adjustments to optimize wireless coverage. These innovative access points provide the highest-performance 802.11n connectivity for mission-critical mobility. By intelligently avoiding interference, the 3500 Series offers performance protection for 802.11n networks to help ensure reliable application delivery.
- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Line
- Aironet
- Product Series
- 3500
- Product Condition
- Refurbished
- Product Type
- Wireless Access Point
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Wireless LAN Standard
- IEEE 802.11n
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Minimum Frequency
- 2.41 GHz
- ISM Maximum Frequency
- 2.46 GHz
- UNII Minimum Frequency
- 5.18 GHz
- UNII Maximum Frequency
- 5.83 GHz
- Antenna Gain (Isotropic)
- 6 dBi
- Wireless Transmission Speed
- 300 Mbit/s
- Wireless Security
- AES
- TKIP
- EAP
- TLS
- TTLS
- MSCHAPv2
- PEAP
- EAP-MSCHAPv2
- WPA2
- WPA
- IEEE 802.11i
- IEEE 802.1X
- Features
- MIMO Technology
- Rugged
- Interfaces/Ports
- Ethernet Technology
- Ethernet
- Fast Ethernet
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 1
- Network (RJ-11)
- No
- PoE (RJ-45) Port
- No
- VGA
- No
- HDMI
- No
- Audio Line Out
- No
- Serial Port
- No
- USB
- No
- Powerline
- No
- Management Port
- Yes
- Management & Protocols
- Management
- Cisco Unified Wireless Network Software Release 7.0 or Later
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Physical Characteristics
- Form Factor
- Ceiling Mountable
- Height
- 1.8"
- Width
- 8.7"
- Depth
- 8.7"
- Weight (Approximate)
- 2.30 lb
- Miscellaneous
- Certifications & Standards
- Safety:
- UL 60950-1
- CAN/CSA-C22.2 No. 60950-1
- UL 2043
- IEC 60950-1
- EN 60950-1
- FCC Part 15.247, 15.407
- RSS-210
- EN 300.328
- EN 301.893
- ARIB-STD 33
- ARIB-STD 66
- ARIB-STD T71
- AS/NZS 4268.2003
- EMI and susceptibility (Class B)
- FCC Part 15.107
- FCC Part 15.109
- ICES-003
- VCCI
- EN 301.489-1 and -17
- EN 60601-1-2 EMC requirements for the Medical Directive 93/42/EEC
- 802.11a
- 802.11g
- 802.11n
- 802.11i
- 802.1X
